MA-I1BA-868
868MHz 12dBi Fiberglass Baton
The Midland Antennas MA-FB-868 is a fiberglass, baton-style antenna crafted for reliable use in the Sub-1 GHz 868 MHz frequency band, making it ideal for low-power, wide-area (LPWA) applications such as LoRaWAN®, Sigfox®, Weightless-P®, WiFi HaLow™, and other ISM and remote control systems.
Providing omnidirectional coverage, designed for outdoor deployment in applications like base stations where robust, continuous performance is essential.
The MA-FB-868 offers a range of gain options—3 dBi, 5 dBi, 5.8 dBi, 8 dBi, 10 dBi, and 12 dBi—allowing for tailored solutions based on specific signal requirements. The length of the antenna scales proportionally with gain, ranging from a compact 35 cm to 150 cm.
Built with a weather-resistant, fully waterproof fiberglass radome, the antenna ensures durability in harsh environments.
The MA-FB-868 comes standard with an N-Type connector, and custom connectors are available upon request.
Electrical Data
Mechanical Data
| Frequency Range | 868MHz |
| Gain | 3 dBi, 5 dBi, 5.8 dBi, 8 dBi, 10 dBi, or 12 dBi |
| Polarisation | Vertical |
| Horizontal Half Power Angle | 360° |
| Vertical Half Power Angle | 32° |
| Front to Back Ratio | ≥15dB |
| Max Input Power | 50W |
| V.S.W.R | ＜1.5 |
| Input impedance | 50Ω |
| Lightning Protection | DC Ground |
